DKM Navy Type VII-B U-Boat 83504

Model:83504
The proportional model:1:350
Browse the number:7933

Add to Favorites

Comment


Product introduction:

      The only significant drawback of the VIIA was the limited fuel capacity, so 24 Type VIIB boats were built between 1936 and 1940 with an additional 33 tons of fuel in external saddle tanks which added another 2500 miles (4625 km) of range at 10 knots (19 km/h) surfaced. They were slightly faster than the VIIA, and had two rudders for even greater agility. The torpedo armament was improved as well by moving the aft tube to the inside of the boat. Now an additional aft torpedo could be carried below the deck plating of the aft torpedo room (which also served as the electric motor room) and two watertight compartments under the upper deck could hold two additional torpedoes giving it a total loadout of 14 torpedoes. The only exception was U-83 , which lacked a stern tube and carried only 12 torpedoes.

Parament
Item No    83504
Item Name    DKM Navy Type VII-B U-Boat
Bar Code    6939319235046
Scale    1:350
Item Type    Static kit
Model Dimension    Length: 191mm   Beam: 18.2m
Total Plastic Parts    58pcs
Total Sprues    2 sprue, upper hull and lower hull
Chromeplate Parts    n/a
Camouflage Scheme    German Navy
Resin Parts    n/a
Metal Parts    n/a
Photo Etched Parts    2pcs
Film Accessory    n/a
Released Date    2010-03
More Features The kit consists of  35 parts in light grey plastic,23 Photo etched parts
- Photo Etched parts for handrails and stand.
